What Is Bit Depth?

Bit depth, also called color depth or colour depth, is either the number of bits used to indicate the color of a single pixel or the number of bits used for each color component of a single pixel. When referring to a pixel, the concept can be defined as bits per pixel (bpp). When referring to a color component, the concept can be defined as bits per component (bpc), bits per channel (bpc), bits per color (bpc), and also bits per pixel component, bits per color channel, or bits per sample (bps, sample rate).

Color bit depth is only one aspect of color representation, expressing the precision with which the amount of each primary can be expressed; the other aspect is how broad a range of colors can be expressed (gamut). The definition of both gamut and color precision is accomplished with a color encoding specification that assigns a digital code value to a location in a color space.

Common Bit Depths

The following is a table listing the popular image bit depths and their corresponding number of colors.

Common Bit Depths Number of Colors
1-bit color 2 (21)
2-bit color 4 (22)
3-bit color 8 (23)
4-bit color 16 (24)
5-bit color 32 (25)
8-bit color 256 (28)
12-bit color 4,096 (212)
15/16-bit color (high color) 32,768 (215)/65,536 (216)
18-bit color 262,144 (218)
24-bit color (true color) 16,777,216 (224)
30-bit color (deep color) 1,073,741,824 (230)
36-bit color 68,719,476,736 (236)
48-bit color 281,474,976,710,656 (248)

Color depth Xbox Series X

By default, Xbox Series X drops the color sampling when it detects an HDMI 2.0 port to a more compressed 4:2:0 signal with a color depth of 10 bits.

Xbox One color depth

Xbox One can export signals at 8-bit (24 bits per pixel), 10-bit (30 bits per pixel), and 12-bit (36 bits per pixel).

failed to play test tone thumbnail
Failed to Play Test Tone on Windows 10? Easily Fix It Now!

Have you received the error failed to play test tone when testing your speaker or headphone? Try these solutions mentioned in this post to fix it.

Read More

What Is Bit Depth in Audio?

In digital audio using pulse-code modulation (PCM), bit depth is the number of bits of information in each sample. It corresponds to the resolution of each sample directly. For instance, compact disc digital audio uses 16 bits per sample (16-bit color depth); DVD audio and Blu-ray disc supports up to 24 bits per sample (24-bit color depth).

In basic implementations, variations in bit depth audio primarily affect the noise level from quantization error and further influence signal-to-noise (SNR) and dynamic range. Yet, technologies like dithering, noise shaping, and oversampling will mitigate those effects without changing the bit depth.

Audio bit depth also affects bit rate and file size. Bits are the basic unit of data used in computing and digital communications. Bit rate refers to the amount of data (especially bits) delivered or received per second. In lossy compressed audio formats like MP3, bit rate describes the amount of information used to encode an audio signal. Usually, it is measured in kb/s.

As the bit depth increases, the file size also increases for more color information need to be saved for each pixel in the picture. For photos that naturally have few colors, you may reduce their sizes greatly without degrading their quality.

Bit depth is only meaningful for a PCM digital signal. Non-PCM formats don’t have associated bit depths, such as lossy compression formats.

audio bit depth

How to Change Bit Depth Windows 10/11?

If you are not satisfied with the color representation of your computer monitor, you can adjust it by changing bit depth, brightness, resolution, refresh rate, HD color, etc. Here, we will only show you how to alter the bit depth of a Windows display.

1. Navigate to Start > Settings > System > Display > Advanced Display.

2. Find the option starting with “Display adapter” and click on it. Here in my Windows 11, it is Display adapter properties for Display 1.

display adapter properties Windows 11

3. In the new window, select the List All Modes button.

4. In the popup, select a color mode you prefer and click OK to save the changes. You are recommended to select a color mode with higher bit depth to display more colors and get a better visual experience.

change bit depth Windows 11

5. Click Apply.

Conclusion

Bit depth refers to the color info saved in an image. The higher the bit depth, the more colors it can store. The simplest 1-bit image can only display two colors; that is black and white. That is because the 1 bit can only contain 1 or 2 values, 0 (white) and 1 (black).
